2D and 3D fingerprint capture in high-intensity environments

The TerrainX was built to withstand the rigors of travel and operation in high-intensity environments. This device enhances our Terrain with a hardened base and cover for additional protection. With all the Terrain features and more, this easy-to-use device produces exceptional results in both 2D and 3D imagery.

Contact us to purchase

SKU: terrainx-1 Category: Tags: ,


For security professionals seeking extra field protection and 3D imaging

  • FBI-certified Appendix F livescan.
  • Designed for rugged environments.
  • U.S.-based manufacturing and support.
  • Captures high-quality 2D and 3D imagery.
  • Corrosion resistance increase protection.

Standards & specifications

  • Resolution: 500 ppi in the platen plane (FBI certified).
  • Variable resolution into the nanometers moving away from the platen
  • Weight: 5.25 lbs
  • Size: 5.5” x 8.5” x 6.3”
  • SDK available with coding examples and utility code.
  • Image capture sizes configurable
  • Supports USB 3 with a Type-C connector
  • Can be used with a Type-A USB 3 connector with an adapter
  • Driverless installation for Windows 10 and 11
  • High frame rates for quick capture
  • RoHS compliant
  • FCC part 15 and ICES-003 compliant
  • Corrosion resistant
  • CJIS Appendix F certified

Additional information

Terrain series livescans  (4 MB)


Maintenance & support

Each Terrain device comes with a one-year warranty. Depending on your company’s needs, warranty extensions are available to ensure your device is always protected.
